Fan Coil W-Type

Copra F-Type Fan Coils for floor mounting

  • Fan coil unit with casing
  • Heating and cooling applications
  • Remote controlled operation

Copra Fan Coils are made to meet the strict requirements of the marine industry. They are highly reliable and made through close cooperation with our customers. The compact size and easy installation make them easy to fit onboard your ship.

The W-Fan Coil is available in 3 different sizes, ranging from 3.6kW to 7.2kW in cooling capacities.

COPRA Fan Coil W-Type
COPRA W 3.6 COPRA W 4.5 COPRA W 7.2
Power Supply 220V,60Hz,1Ph
Air Volume H m3/h 680 850 1360
M m3/h 510 637,5 1020
L m3/h 340 425 680
Cooling Capacity H W 3618 4514 7210
M W 3075 3837 6129
L W 2352 2934 4687
Heating Capacity H W 5418 6767 10807
M W 4605 5752 9186
L W 3522 4399 7025
Noise Level dB(A) 43/40/37 47/43/40 49/45/41
Fan Motor Fan Quantity 1 1 1
Motor Quantity 1 1 1
Power Input W 62 76 134
Water Flow Volume kg/h 800 950 1390
Hydraulic Resistance kPa 30 30 40
Max.Working pressure MPa 1,6 1,6 1,6
Dimension(W×D×H) Net mm 850×300×198 970×315×235 1100×330×235
Packing mm 885×360×270 1010×380×300 1140×390×300
Net/Gross Weight kg 12.6/14.5 15/17 20/23
Inlet/Outlet Water Pipe Rc1/2″(DN15) Rc1/2″(DN15)
Drain Pipe Rc1/2″(DN15) R1/2″(DN15)
